Description
Designed specifically for use with Model 702, Model 725, Model 25SF,and Model 25SP with 2.5 in square flange, this Single Pivot Bracket allows for convenient mounting of an encoder and measuring wheel over the surface being measured. The gravity-loaded bracket uses the combined weight of the encoder, measuring wheel, and bracket to provide surface torsion, while the single pivot action allows the assembly to adjust pitch for variations in material height. For more information, please refer to Technical Bulletin TB-528: Pivot Bracket Installation or contact Customer Service.
